DT48-EM panel temperature controller - PID and ON/OFF

Product description:
The DT48-EM is a single-channel panel temperature controller designed for heating with a universal input. It can be used for precise temperature control in industrial applications, light industrial machinery, food processing, ovens and other systems where precise heating control is required.

Inputs:

• Pt100 resistance sensor

• J, K, T, T, R, S type thermocouples (T/C)

Outputs:

• for resistive load SPDT relay 2A / 250VAC

• Digital output 12VDC / 20mA for controlling SSR relays

Dimensions:

• 230VAC power supply.

Functions and features

• Control: PID and ON/OFF, optionally P, PI, PD

• Automatic PID tuning: self-optimization to minimize overshoot .

• Ramp mode: continuous temperature increase upon power-on

• Anti-windup: protection against the rise of the control output in PID/PI

• Upper and lower limit: to set the desired SET temperature

• Two-line display: Sv (set value) and Pv (actual value)

• Compensation: cold junction for T/C, wire resistance for Pt100

• Linear conversion: °C/mV and °C/Ohm tables

• Offset: offset of values ​​in the entire range

• Password protection: prevents unwanted changes to settings

• EEPROM memory: retains settings even after power is turned off .

• Easy connection: 5.08 mm plug-in connectors

Measuring ranges according to sensor type

Comment:
Even though the controller can measure temperatures below -20 °C and above +55 °C, the device itself must be installed in an environment with a temperature of -20 ... +55 °C , otherwise the plastic housing may deform and the thermostat may fail.
