PID panel temperature controller - TENSE DTZ-48

DTZ-48 is a panel temperature controller with a built-in timer, designed for precise control of thermal processes used in industry, heating, air conditioning, ventilation systems and building automation.

Control is performed either with classic ON/OFF mode or with advanced PID control with self-optimization and process value exceedance limitation.

Main features

• Temperature measurement range: -100 °C to +1750 °C (depending on sensor type)

• Sensor type: T/C thermocouples (J, K, T, S, R) or Pt100 resistance sensor

• Control type: P, PI, PD, PID or ON-OFF

• Built-in timer for process control

• Automatic tuning of PID parameters

• Anti-windup - prevents the control output from increasing during saturation

• Output on delay in cooling mode

• Password protection

• EEPROM memory for storing settings

• Control output: relay OUT (NO+NC) 250 VAC, 2A

• Alarm output: ALARM relay (NO+NC) 250 VAC, 2A, active when the value is exceeded or undershot (enabled only for DTZ-48).

• Display: High contrast, easy to read even in low light conditions

Functions

• Precise temperature control with sensor-specific measuring range setting

• The controller allows simultaneous display of the set and current values

• Built-in timer allows you to schedule heating or cooling processes

• Alarm relay warns when the value is exceeded or not reached

Recommended sensor

• J Fe-Const type thermocouple (6/8 meters)

• Measuring range: -100 °C to +600 °C

• Cable lengths: 1 m, 1.5 m, 2 m, 2.5 m, 3 m, 4 m and 5 m

Application

• Heating and cooling control in industrial furnaces and lines

• Temperature control of machines and equipment in the food, chemical and light industries.

• Building automation and air conditioning systems

• Applications where reliable alarm output is required
