Vendor: TENSE

Delay ON-DELAY OFF-DELAY Time relay LED display for panel/door mounting

Barcode: ERD-96T
27.390 Ft
27.390 Ft
27.390 Ft
Low stock: 5 left
Height x width: 96mm x 96mm
  • Description
  • User manual
  • Payment methods
  • Guarantee

Time relay for ERD-72T panel with display - ON/OFF delay

Description:
The ERD-72T panel-mounted time relay allows for on-delay / off-delay with a time setting of up to 999 minutes. Thanks to the display and easy operation of the buttons (arrows), setting the time is quick and easy.

Main features

  • Time setting: 0.1 s - 999 minutes (16 hours 39 minutes)

  • Status indication:

    • green LED OUT - relay closed (COM-NO)

    • Red LED TRG - signal present at the TRG terminal.

  • Output relay: switching, COM, NO, NC terminals

  • Universal power supply: 24 V AC/DC (A2(-), A3(+)) or 230 V AC (A1-A2)

  • Power consumption: <6 VA

  • Mounting: in panel/cabinet door

  • Dimensions: 72 × 72 × 51 mm

Features

Power-off delay:

  • Immediate relay tripping on the rising edge of the TRG signal.

  • The relay remains on for a set time.

  • The display counts down the time until the release

Power-on delay:

  • Delayed release of the relay after the set time has elapsed from the incoming edge of the TRG signal.

  • Countdown to power on display

  • The relay remains on until the next rising edge of the TRG signal.

  • If the signal remains at the TRG signal, the relay remains on.

Using the website

  • Instant on when signal is applied to TRG.

  • Delayed switch-on for load (alarm, lighting, contactor).


Download the

User manual
