3-phase network analyzer TPM-01ESH - TENSE (Turkey)
Description:
Multifunctional digital panel meter for three-phase network parameters, designed for accurate measurement and control of electrical values. Allows monitoring of currents, voltage, frequency, power and energy with RS485 ModBus RTU communication capability.
Main functions
-
Measuring three-phase voltage and current
-
Display of active, reactive and apparent energy (P, Q, S)
-
Display of Cosφ and power factor values of each phase
-
Measurement of phase-neutral and phase-phase voltage and current of each phase
-
Frequency measurement
-
Harmonic voltage and current up to the 31st harmonic
-
Total active energy import and export values (ΣkWh)
-
Total inductive and capacitive reactive energy (ΣkVArh)
-
Display of minimum and maximum values, maximum requirements
-
2 relay outputs and 1 digital input
-
Event logs (voltage/current high/low, unbalance, THD-I)
-
Password protected menu
Technical characteristics
-
Communication: RS485 ModBus RTU (1200-38400 bps)
-
Connection: 3-phase voltage transformer and 3-phase current transformer
-
Compatible current transformers: 60/5, 75/5, 100/5, 150/5, 200/5, 250/5, 300/5, 400/5, 500/5, 600/5, 800/5, 1000/5, 1500/5
-
Panel size: standard digital mounting panel
Application
-
Monitoring of three-phase electrical networks in industrial and commercial applications.
-
Monitoring energy consumption and power quality
-
Integration into automation systems via ModBus RTU
