ONKA 4mm2 spring terminal connector DIN rail connector gray, 2 wire, 1020024

Spring terminal block / DIN rail connector 2-wire, retractable contact, gray, ONKA, made in Turkey

The ONKA compact terminal blocks provide great opportunities for connecting any wires of different cross-sections. Thanks to the transparent housing, the correct arrangement of the wires can be easily checked. The original ONKA quick connectors ensure convenient installation and 100% connection reliability.

Technical parameters

The cross-section of the connected single wire is up to: 4mm2
Color: gray
The main housing insulating material: polyamide (PA6.6)
Contact/bridge material: stainless steel/copper
Connection position: top / top
Cable strip length: 9mm
Type of electrical connection: spring clamp / retractable contact
Rated voltage: 750V
Rated current: 32A
Operating temperature range: -40°C
Operating temperature range: up to 140°C
Mounting method: DIN 35 mm mounting rail
Standard: EN-60947-7-1
